Refill pouch 500 ml dieline
Hand-wash, shampoo or detergent refill with a wide corner spout. A ready-sized preset of the spout pouch — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside140 × 220 mm
Outside140 × 220 mm
Flat blank140 × 220 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 140 · Height 220 mm
- Size range
- Width 60–320 · Height 90–450 mm
- Manufacturing
- 140 × 220 mm score to score · inside vs outside sizes
- Parts
- 3 parts — Front web, Back web, Bottom gusset
- Board area
- 0.071 m² · about 18 up on a 720 × 1020 mm sheet
- Default board
- White PET / PE laminate · 0.09 mm caliper
- Board options
- Met PET/PEWhite PET/PEClear PET/PEKraft/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 10 options; the template and 3D preview follow each change.
- Spout position2 options
- Bottom construction3 options
- Spout diametermm
- Bottom gussetmm
- Corner cutmm
- Cap diametermm
- Cap heightmm
- Cap colour10 options
- Hang / carry hole7 options
- Fill%
The spout pouch family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
