Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureFood
Egg carton, 12 eggs dieline
The dozen: two rows of six large eggs. A ready-sized preset of the egg carton — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside300 × 100 × 68 mm
Outside301.8 × 100.9 × 68.9 mm
Flat blank437.4 × 531.2 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Length 300 · Width 100 · Height 68 mm
- Size range
- Length 60–400 · Width 40–250 · Height 30–120 mm
- Manufacturing
- 301.4 × 100.5 × 68.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.180 m² · about 1 up on a 720 × 1020 mm sheet
- Default board
- Kraft board 350 g · 0.46 mm caliper
- Board options
- Kraft 350SBS 350GD2 350FBB 400SBS 300F-fluteSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Reverse crease
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.46 mm for Kraft board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Base | 301.4 × 100.5 | L + 3T × W + T |
| Front | 301.4 × 68 | L + 3T × H |
| Front roll | 298.5 × 1.9 | – |
| Front (inside) | 298.5 × 51.5 | – |
| Egg cradle | 298.5 × 97.1 | L − T − 1 × cradle |
| Cradle leg | 298.5 × 16 | – |
| Cradle foot | 298.5 × 14 | – |
| Back | 301.4 × 68.5 | L + 3T × H + T |
| Front corner ear ×2 | 40.2 × 67.1 | – × H − 2T |
| Back corner ear ×2 | 40.2 × 67.1 | – × H − 2T |
| Left end | 68 × 99.5 | W − T × H |
| Right end | 68 × 99.5 | W − T × H |
| Lid | 301.4 × 109.7 | L + 3T × W + T − roll/2 |
| Lock tab ×2 | 30 × 14 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 6 options; the template and 3D preview follow each change.
- Eggs alongcount
- Rowscount
- Egg sizemm
- Lock tabscount
- Pull tabon / off
- Windowon / off
